Merida Big Trail 400 Trail MTB
29er aluminium hardcore hardtail with Suntour XCR34 140mm air fork, Shimano Deore 1 x 10 drivetrain and a dropper seat post.
Confirm price and options with the shop
Collect from Wallasey, built and set up for you. How it works
Your bike. Your way to buy.Explore finance, deposits & Cycle to Work.Returns & support
We’re here to help with your purchase. Read our returns and warranty information.
Made for the way you ride.
29er aluminium hardcore hardtail with Suntour XCR34 140mm air fork, Shimano Deore 1 x 10 drivetrain and a dropper seat post.
The Big Trail has been a hit with the mountain bike press and trail riders alike. Bikeboard.cc confirmed that we ‘nailed it’, while MBR, IMB and many more confirmed that the Big Trail is firmly at the top of the trail hardtail game.
Conversations between UK bike shops and our German R&D team resulted in the development of a fun-packed and hugely capable bike. Trail bike geometry combined with a long travel 140 mm fork and grippy 2.4″ wide 29er trail tyres make this the perfect companion for exciting trail sessions and demanding all-day rides over rough terrain. It’s perfectly suited to UK riding.
The modern trail bike geometry has a slack enduro inspired 65.5° head angle, steep seat angle and a long reach. A short seat tube delivers a low standover height giving plenty of space to manoeuvre on the bike when the trail gets technical but still accommodates a long travel dropper post. The geometry means most sizes work for most body sizes so riding style can be factored in. If you want to go crazy fast, take the longer size, for agility, take a shorter size.
Specification, at a glance.
Frame & suspension
| Frame | BIG.TRAIL TFS |
|---|---|
| Frame size | S, M, L, XL, XXL |
| Fork | SR Suntour XCR34 LOR |
Gears & drivetrain
| Chainset | Shimano Deore M5100 |
|---|---|
| Cassette | Shimano Deore M4100 |
| Chain | KMC X10 |
| Shifters | Shimano SL -MT500-L / Shimano Deore M4100 |
| Rear derailleur | Shimano Deore M5120 Shadow+ |
| Pedals | VP VPE-891 |
Braking
| Brakes | Tektro M275 |
|---|---|
| Rotors | Shimano RT10 |
Wheels & tyres
| Rims | MERIDA COMP TR |
|---|---|
| Front tyre | Kenda Regolith |
| Rear tyre | Kenda Regolith |
Cockpit & contact points
| Headset | MERIDA M4455 |
|---|---|
| Stem | MERIDA COMP CC |
| Handlebar | MERIDA EXPERT CC |
| Grips | MERIDA COMP EC |
| Seatpost | MERIDA COMP TR |
| Saddle | MERIDA COMP SL |
| Seat clamp | MERIDA COMP QR |
More about this model
The Big Trail has been a hit with the mountain bike press and trail riders alike. Bikeboard.cc confirmed that we ‘nailed it’, while MBR, IMB and many more confirmed that the Big Trail is firmly at the top of the trail hardtail game.
Conversations between UK bike shops and our German R&D team resulted in the development of a fun-packed and hugely capable bike. Trail bike geometry combined with a long travel 140 mm fork and grippy 2.4″ wide 29er trail tyres make this the perfect companion for exciting trail sessions and demanding all-day rides over rough terrain. It’s perfectly suited to UK riding.
The modern trail bike geometry has a slack enduro inspired 65.5° head angle, steep seat angle and a long reach. A short seat tube delivers a low standover height giving plenty of space to manoeuvre on the bike when the trail gets technical but still accommodates a long travel dropper post. The geometry means most sizes work for most body sizes so riding style can be factored in. If you want to go crazy fast, take the longer size, for agility, take a shorter size.
The Big Trail has hidden talents, in addition to two sets of bottle bosses, there’s a trail mount under the top tube that allows you to carry tools and extra gear on the bike. It’s also possible to fit mudguards and a rack if you want to trek further afield.
A proper bike. Properly looked after.
Your complete bike is professionally built and tuned, with fit advice and suspension setup where applicable.
Three months’ servicing and help from our Wallasey workshop come with the ride. Ask us about BikeRegister registration and fitting compatible accessories.
