FRAME
- TFS – 6061 series aluminium tubing, double butted and technoformed. Tapered head tube. Inboard chain stay mounted disc brake. Internal cable routing and mounts for mudguards and kick stands.
FORK
- Rock Shox Judy TK; Coil; 100mm suspension travel Lockout; 42mm fork offset
WHEEL SIZE
- 27.5″
RIMS
- Merida CC; 17mm inner width; Material: aluminium
SPOKES
- Black steel
FRONT HUB
- Shimano TX505; 100x9mm; 32 spokes; Centerlock
REAR HUB
- Shimano TX505; 135x9mm; 32 spokes; Centerlock
FRONT TYRE
- Merida K1080; 27.5″ x 2.2″; wire bead
REAR TYRE
- Merida K1080; 27.5″ x 2.2″; wire bead
GEARS
- 18
SHIFTERS
- Shimano ST-EF505
FRONT DERAILLEUR
- Shimano FD-M2020-TS
REAR DERAILLEUR
- Shimano RD-M370
CHAINSET
- Shimano MT101-2; 36-22 teeth chainwheel with 170mm – XS/S, 175mm – M/L length crank
CASSETTE
- Shimano CS-HG200; 11-32 teeth; 9 speed
BOTTOM BRACKET
- Shimano BB-UN100 (or FSA TH-7420ST if Shimano supply is delayed)
CHAIN
- KMC M99
PEDAL
- VP Components, VPE-891
BRAKE LEVER
- Shimano BR-MT200 (or Tektro HD-M275 if Shimano supply is delayed)
FRONT BRAKE
- Shimano BR-MT200 (or Tektro HD-M275) hydraulic brake caliper with Shimano RT10; 160mm rotor
REAR BRAKE
- Shimano BR-MT200 (or Tektro HD-M275) hydraulic brake caliper with Shimano RT10; 160mm rotor
GRIP
- Merida EC
HANDLEBAR
- Merida CC; aluminium; 690mm width; 15mm rise
STEM
- Merida CC; aluminium; 31.8mm diameter; 6 degree stem angle – Length : 70 mm-XS/S, 80 mm-M, 90 mm-L
HEAD SET
- Merida M2345
SADDLE
- Merida Sport comfort
SEAT POST
- Merida CC; aluminium; 30.9mm diameter; 15mm setback
SEASON
- 2021
