FRAME
- City Lite II – Hydroformed 6066 triple butted aluminium. 135 x 9mm axle standard. Internal cable routing. Max. tyre size 700 x 50c with mudguards
MOTOR
- Shimano Steps E6100; 60Nm
BATTERY
- Shimano E8035; 504Wh internal battery
BATTERY CAPACITY
- 504Wh
EBIKE DISPLAY
- Shimano SC-E5000
CHARGER
- Shimano EC-E6002; 2A Charging current
POWER BUTTON
- Merida Power Cap button
MODE SWITCH
- Shimano SC-E5000
FORK
- Suntour NEX E25; Coil; 63mm travel. Max. tyre size: 700 x 52c
GEARS
- 9
SHIFTERS
- Shimano Alivio M3100
REAR DERAILLEUR
- Shimano Alivio M3100; SGS
BOTTOM BRACKET
- Part of Shimano Steps motor
CHAIN
- KMC e9S
CHAINSET
- Shimano CRE61; 38 tooth chainring with Shimano FC-E6100; 170mm length crank and chainguard
CASSETTE
- Shimano HG200; 11-36 teeth; 9 speed
BRAKE LEVER
- Shimano MT200
FRONT BRAKE
- Shimano MT200 2 piston hydraulic disc brake caliper with Shimano RT10 180mm rotor
REAR BRAKE
- Shimano MT200 2 piston hydraulic disc brake caliper with Shimano RTEM300 180mm rotor
GRIP
- Merida Expert TK
HANDLEBAR
- Merida Expert; aluminium; 640mm wide; 35mm rise
STEM
- Merida Expert; aluminium; 31.8mm diameter; adjustable – Stem length: 65 mm (XS/S/M), 90mm (L/XL)
HEAD SET
- Merida-8252
PEDAL
- VP Components – VPE-891
SADDLE
- Merida Expert TK; V-mount
SEAT POST
- JD-SP79; 30.9mm diameter; 15mm lay back; 40mm suspension travel
WHEEL SIZE
- 700c
RIMS
- Merida Comp TK; 20mm inner rim width; aluminium
SPOKES
- Black stainless
FRONT HUB
- Shimano TX505; 100x9mm; 32 spokes; Center lock
REAR HUB
- Shimano TX505; 135x9mm; 36 spokes; Center lock
FRONT TYRE
- Continental Ride Cruiser; 622-50; wire bead with reflective strip
REAR TYRE
- Continental Ride Cruiser; 622-50; wire bead with reflective strip
COLOUR
- Red/Black
SEASON
- 2023
FRONT LIGHT
- Hermans H-Black MR4 E, LED front light – 120 Lumens
REAR LIGHT
- Spanninga Commuter Glow XE integrated rear light
OTHER
- Complete with: Kickstand, Abus frame lock, chainguard, mudguards, carrier with spring clip and front / rear lights. Shimano Satellite charging port; EW-CP100
